AI + AUTOCAD AUTOMATION
Stop redrawing the same plans by hand.
I connect AI to your AutoCAD drawings, so your small team sets up sheets, schedules, and plans faster, with fewer mistakes.
20,000+ YouTube subscribers. Teaching AutoCAD since 2017.
Who this is for
Small architecture and engineering firms, and contractors, that draw the same kinds of plans again and again.
Three problems I solve
Repeated drawings take hours
The same plan types get redrawn from scratch on every job.
Standards get lost
When many people draw, layers, blocks, and styles drift apart.
One person knows the files
Only one teammate understands how the drawing files are set up.
A REAL EXAMPLE: RESTAURANT REMODEL DRAWINGS
About 50% less time on construction documents
This is my own estimate on my restaurant remodel projects.
1. Sheets set up for me
My agent sets up every sheet (T1.0, A1.0, A2.0 and more) with my xref title block for that project. It also adds the north arrow and the baseplan. About 95% of this work is now automatic.
2. Baseplan ready to annotate
On every sheet it freezes layers and changes the colors and linetypes of the baseplan. I open the sheet and start annotating.
3. Schedules and cover sheet
It builds schedules like lighting on the RCP, equipment on the kitchen plan, and power on the electric plan. By hand, schedules can take about 15% of CD time. It can also update my T1.0 cover sheet with the applicable codes and areas.
Your files stay safe. The AI only looks at the specific folder you tell it to. Nothing else on your computer or network.
Your results will depend on your files and standards. We measure them together.
How it works
1. Review
We look at your real drawings and pick the biggest time waster first.
2. Build and test
I build the automation and test it on your own files.
3. Train and measure
Your team learns it, and we track the time it saves.
An honest note
This is a new specialty that I am still developing. Pilot projects have a lower rate in exchange for your feedback.
